Reheating Test Furnace
Published: 8/24/2021
The CSL-II Reheating Test Furnace is designed for reheating and sintering refractory products while measuring reheat linear change under various atmospheres. It is built to comply with GB/T 5988 requirements for dense shaped refractories.
Product Description
The CSL-II Reheating Test Furnace serves as a high-temperature heating and sintering platform for refractory materials and is widely used in metallurgy, building materials, machinery, and chemical industries. It is specifically engineered to evaluate the reheat linear change of refractory products under controlled atmospheres during thermal cycles.
The system employs intelligent PID temperature control with multi-segment programmability to execute precise heating ramps and soaks. Its control accuracy and stability are suited for rigorous lab testing and production quality control, and it supports computer connectivity for fully automatic operation with a user-friendly interface.
Technical Specifications
| Parameter | Specification |
|---|---|
| Standards | GB/T 5988 (Dense shaped refractories—Reheat linear change test method) |
| Operating Temperature (Option 1) | 1650 ℃ |
| Short-Term Maximum Temperature (Option 1) | 1700 ℃ |
| Operating Temperature (Option 2) | 1700 ℃ |
| Short-Term Maximum Temperature (Option 2) | 1750 ℃ |
| Temperature Control Accuracy (Soak) | ±1 ℃ (constant temperature zone) |
| Temperature Control Accuracy (Ramp) | ±2 ℃ |
| Heating Rate | 0–10 ℃/min, programmable |
| Hold Temperature Precision | ±2 ℃ |
| Control Mode | Intelligent PID, 50-program segments |
| Power | 6–36 kW |
| Automation | Computer connection for fully automatic control |
| User Interface | Chinese operation interface |
