Dynamic Contact Angle and Surface Tension Analyzer
Published: 6/29/2023
Video-based system for measuring contact angle, surface/interfacial tension, wettability, and adsorption on solid and liquid interfaces. Suited for industrial and academic R&D requiring dynamic and static droplet analysis with automated image processing.
Product Description
The FTA-II is a flexible video-based analyzer designed to characterize liquid–solid and liquid–liquid interactions, including contact angles, surface and interfacial tensions, wettability, and adsorption behavior. It captures dynamic and static droplet events and analyzes droplet size and shape to compute target properties, presenting results graphically and enabling export to databases or spreadsheets.
The system provides real-time visualization on a PC, stores image sequences for post-processing, and supports continuous or event-triggered acquisition. Automated image analysis is complemented by semi-automatic and manual modes for complex profiles, with explicit edge detection visualization to verify algorithm performance. Optional environmental and motion-control accessories extend capability to temperature-controlled, pressurized, tilted, or large-sample scenarios.
Technical Specifications
| Parameter | Specification |
|---|---|
| Measured Parameters | Static/equilibrium contact angle; Capillary contact angle; Advancing angle; Receding angle; Pendant-drop surface tension; Pendant-drop interfacial tension; Sessile-drop surface tension; Sessile-drop spreading; Sessile-drop absorption; Surface energy; Work of adhesion/adhesional tension; Critical micelle concentration (CMC); Zisman critical wetting tension |
| Contact Angle Precision (Std. Dev.) | < 1° |
| Surface Tension Precision (Std. Dev.) | < 0.5 mN/m |
| Contact Angle And Tension Resolution | 0.1 unit |
| Frame Capture Rate | 60 frames/s to 1 frame per several hours (nonlinear scheduling supported) |
| Acquisition Modes | Continuous, event-triggered (e.g., drop formation), user-triggered |
| Analysis Basis | Droplet size and shape from grayscale images; graphical display and data export supported |
| Imaging Hardware | High-resolution camera; imaging microscope with magnification optics |
| Motion And Dosing | PC-controlled syringe pump; controllable sample stage; precision motorized platforms (optional) |
| Illumination | PC-controlled light source |
| Supported Sample Formats | Large samples and non-horizontal bottom surfaces |
| Optional Modules | Environmental chamber (up to 300 °C); internal platform axial travel; large sample chamber with circulating bath and 3-axis platform; interfacial tension chamber with circulating bath and pressure capability; syringe heater; tilting stage; 360 fps camera; auto-zoom/auto-focus microscope; preloaded PC |
