Automatic Glass Softening Point Tester
Published: 1/6/2025
Automatic tester for determining the softening temperature of glass fibers via displacement tracking and software-driven analysis. Compliant with GB/T 28195-2011 and ASTM C338 methods for softening point evaluation.
Product Description
The PCY-SP Automatic Glass Softening Point Tester measures the softening temperature of glass fibers by continuously tracking fiber elongation under controlled heating conditions. A grating or laser displacement sensor follows the fiber’s extension, while a host software acquires data in real time and analyzes the elongation rate to determine the softening point.
The system employs intelligent PID temperature control with programmable heating segments and rates, providing stable and precise thermal profiles for testing. It integrates separate thermocouples for furnace control and specimen measurement to ensure accurate temperature feedback and analysis aligned with GB/T 28195-2011 and ASTM C338 requirements.
Technical Specifications
| Parameter | Specification |
|---|---|
| Rated Temperature | 1200 ℃ |
| Usable Temperature | 1000 ℃ |
| Maximum Heating Capability (Heater Theoretical) | 1350 ℃ |
| Heating Element | Ni-Cr wire (2080) |
| Temperature Control | Intelligent PID, programmable heating segments and rates |
| Temperature Control Accuracy | ±1 ℃ |
| Thermocouples | S-type (control thermocouple and sample thermocouple) |
| Displacement Tracking System | Laser or grating displacement sensor, automatic tracking |
| Displacement Measurement Accuracy | ±0.5% FS |
| Data Acquisition | Automatic via host software with on-screen display |
| Control Modes | User-selectable temperature control mode and program mode for heating rate |
| Standards Compliance | GB/T 28195-2011; ASTM C338 |
