Hydraulic Compression Testing Machine
Published: 10/31/2016
Hydraulic compression tester for determining compressive and flexural strength of cement, mortar, concrete specimens, and other non-metallic building materials. The system uses hydraulic loading with electronic force measurement and digital display, complying with GB/T 3722 requirements.
Product Description
The SYD Hydraulic Compression Testing Machine is designed for compressive strength testing of cement, mortar cubes, concrete specimens, and bricks, and can also perform flexural strength tests when equipped with the bending accessory. It employs hydraulic loading and an electronic load measuring system to provide stable, accurate force control and results suitable for laboratory and quality control environments.
The instrument features digital indication of load, load rate display, peak load capture, overload protection, and data retention on power loss. A screw-driven adjustment quickly sets the compression space, and the machine is delivered ready to operate after oil filling and power connection; on-site calibration can be performed following the user manual.
Technical Specifications
| Parameter | Specification |
|---|---|
| Maximum Load Options | 30 kN; 50 kN; 100 kN; 200 kN; 300 kN |
| Relative Indication Error | ±1% |
| Hydraulic Pump Rated Pressure | 25 MPa |
| Flexural Roller Diameter | 30 mm |
| Maximum Distance Between Upper And Lower Flexural Rollers | 165 mm |
| Center Distance Between Two Upper Flexural Rollers | 150 mm |
| Center Distance Between Two Lower Flexural Rollers | 450 mm |
| Bearing Plate Size | 155 mm |
| Maximum Distance Between Upper And Lower Compression Platens | 230 mm |
| Piston Diameter × Maximum Stroke | 125 mm × 80 mm |
| Piston Stroke | 120 mm |
| Motor Power | 0.75 kW |
| Overall Dimensions (W × D × H) | 850 × 600 × 1340 mm (subject to as-shipped configuration) |
| Standards Compliance | GB/T 3722 |
| Display Functions | Load, load rate, peak load |
| Protection Functions | Overload protection, power-loss data hold |
| Adjustment Mechanism | Rotating screw for rapid compression space adjustment |
| Optional Modules | Constant-pressure test module (specify on order) |
| System Configuration | Main testing machine; hydraulic power/control cabinet; digital display unit; oil pressure sensor |
