Mineral Wool Thermal Conductivity Tester
Published: 3/20/2019
The DRH300 is a flat-plate heat flow meter system for measuring thermal conductivity and thermal resistance of insulation and low-conductivity materials. It complies with ASTM C518, ISO 8301, and GB/T 10295 for rapid, automated testing and reporting.
Product Description
The DRH300 thermal conductivity tester uses the heat flow meter method with symmetrical sample configuration between a heated plate and a cooled plate to evaluate insulation materials such as mineral wool, rubber, insulation boards, ceramics, plastics, clays, and sands. Precise plate temperature control and dual heat-flow sensors enable fast stabilization and high repeatability, allowing users to obtain accurate thermal resistance values in minutes for quality control and process monitoring.
The system supports fully automated operation from temperature control through data acquisition, analysis, report generation, printing, and data storage. Depending on user requirements, it can be configured with an embedded computer and touchscreen HMI to complete automatic testing and data management.
Technical Specifications
| Parameter | Specification |
|---|---|
| Standards Compliance | ASTM C518; ISO 8301; GB/T 10295 |
| Method | Flat-plate heat flow meter, symmetrical sample configuration with heat and cold plate heat-flow sensors |
| Thermal Conductivity Range | 0.005 to 2.0 W/(m·K) |
| Accuracy | < ±3% (at 25°C ambient) |
| Repeatability | ±1% |
| Thermal Resistance Range | 0.1 to 8.0 m²·K/W |
| Sample Size | 300 × 300 mm |
| Sample Thickness | 10 to 50 mm |
| Hot Plate Maximum Temperature | 100°C |
| Cold Plate Minimum Temperature | −30.0°C (±0.1°C), with thermostatic control |
| Hot-Side Temperature Control Range | Room temperature to 99.99°C |
| Temperature Measurement Resolution | 0.01°C |
| Temperature Measurement Accuracy Class | 0.1 class |
| Hot Plate Control | Flat plate heater with bidirectional SCR; automatic intelligent PID |
| Programmable Temperature Points | > 10 |
| Cooling Options | Forced air; external water bath; thermoelectric (electronic) cooling (user selects one) |
| Automation | Computer-based automatic testing, data acquisition, analysis, reporting, and storage |
| Custom Options | Test temperature range customizable |
| Typical Configuration | Main tester; analysis software; low-temperature bath; PC and printer (user-supplied) |
