Glass Thermal Expansion Coefficient Tester (Horizontal)
Published: 9/4/2023
The PCY-III-1200 is an automated horizontal dilatometer for precise measurement of the thermal expansion coefficient of glass. It supports broader thermo-mechanical studies such as softening point, glass transition, sintering kinetics, and phase changes across diverse materials.
Product Description
PCY-III-1200 is designed for accurate determination of the thermal expansion behavior of glass using a horizontal push-rod configuration. The system integrates intelligent temperature control and PC-based software for setup, data acquisition, archiving, and report output.
Typical applications include measurement of thermal expansion coefficient, softening temperature, glass transition temperature, phase transformation behavior, density change with temperature, and rate-controlled sintering studies. It is suitable for glass, ceramics, building materials, polymers, refractories, metals, and alloys.
The instrument is supplied with a test host, software, integrated furnace, quartz sample holder, and a quartz reference standard; a computer is user-provided. Quartz fixtures support solid and powder specimens when used with dedicated molds.
Technical Specifications
| Parameter | Specification |
|---|---|
| Furnace Temperature Range | Ambient to 1200 ℃ |
| Heating Rate | 0.1–20 K/min, user-set; typical control ≤ 5 K/min; PID control and PC communication; full-process adjustable/lockable |
| Measured Expansion Range | 5000 μm |
| Expansion Measurement Error | ±0.1% |
| Temperature Control Accuracy | ±1 ℃ |
| Recorded Temperature Value Error | ≤ ±0.5% |
| Displacement Sensor Resolution | ≤ 1/10000 mm |
| Sample Size | Length up to 50 mm; Diameter 5–10 mm (max); special sizes customizable |
| Sample Forms | Solid; Powder (with test mold) |
| Sample Holder Material | Quartz |
| Primary Functions | Thermal expansion coefficient; Softening temperature; Glass transition; Sintering kinetics; Phase transformation; Density change; Rate-controlled sintering (RCS) |
| Standard Configuration | Test host (1); Test software (1 set); Integrated heating furnace (1); Quartz holder (1 set); Quartz reference standard (1); Computer (user-supplied) |
